- Case Report
- Open Access
Death by late presenting of diaphragmatic hernia in an infant: case report and review of the literature
Egyptian Journal of Forensic Sciences volume 12, Article number: 39 (2022)
Congenital diaphragmatic hernia (CDH) is a congenital malformation of the diaphragm, resulting in the herniation of the abdominal organs into the thoracic cavity. If not properly diagnosed before or at birth, CDH represents a life-threatening pathology in infants and a major cause of death. We present a fatal case of congenital diaphragmatic hernia corresponding to Bochdalek hernia, discovered incidentally during a sudden death’s autopsy of an infant. To achieve a better view of the range of these anomalies, we also conducted a literature review on this subject describing the pathogenesis, manifestations, diagnosis, and autopsy contribution to addressing these CDH.
The case involved a 4-month-old female infant who presented sudden respiratory difficulties after breastfeeding. External examination found marked cyanosis with no evidence of trauma. Upon opening the chest cavity, the stomach, markedly distended, was occupying much of the left pleural cavity. The left lung was compressed and displaced superiorly, and the heart was also compressed and deviated to the right. This mediastinal deviation was due to an ascension of the stomach into the chest cavity through a 2 × 1.5 cm defect in the posterior left hemidiaphragm. Further examination remarked an ecchymotic appearance of the stomach portion entrapped in the hernia defect suggesting recent strangulation of the stomach. The lungs showed atelectasis with signs of pulmonary infection in the histology study.
CDH might be considered uncommon and not always mentioned in the list of sudden death in infant causes. Forensic pathologists should know of this malformation in order to apply the best autopsy techniques and thus allow positive feedback to pediatricians considering the possible legal implications.
Congenital diaphragmatic hernia (CDH) is an uncommon condition in which the diaphragm does not fully form or fuse during embryologic development, resulting in communication between the thoracic and abdominal cavities (Karamanoukian and Glick 2003; Clugston and Greer 2007; Keijzer and Puri 2010). This anomaly accounts for 8% of all major congenital anomalies, with an incidence of 1 in 2000 to 4000 births (Centers for Disease Control and Prevention 2016) and between 1/2000 and 1/7000 cases in autopsy series (Salaçin et al. 1994; Chhanabhai et al. 1995). The posterolateral Bochdalek hernia is the most common form of CDH (70 to 95%) (Greer 2013) named after Victor Bochdalek, who described patients with this defect in 1848 (Loukas et al. 2008). Although most cases are symptomatic at birth, some cases remain asymptomatic until spontaneous or exacerbated herniation of the abdominal viscera into the thoracic cavity occurs (sometimes until adulthood). A wide spectrum of clinical presentations including various associations of respiratory and gastrointestinal symptoms is described, mainly depending on the nature of the displaced viscera. These late cases (beyond 1 month old) account for 2.6 to 20% of all CDH (Bagłaj and Dorobisz 2005; Muien et al. 2021) and carry a high mortality rate of 20 to 35% (Woodbury et al. 2019; Muien et al. 2021). Due to its milder and more perplexing clinical presentation, this type of CDH poses a significant diagnostic challenge, which can lead to misdiagnosis. In such cases, an autopsy is a valuable means of addressing a misdiagnosis. The undertaken medicolegal investigations enable to draw off an evocative epidemiological profile, through case reports or series of cases. An autopsy is indeed a process that studies both the postmortem dimension and the antemortem history, full of clinical data, sometimes atypical, but which makes all the specificity of this rare case of incidental autopsy findings. We report a fatal case of CDH corresponding to Bochdalek hernia, discovered incidentally during an infant autopsy. In order to achieve a better view of these anomalies, we conducted a literature review on this subject describing the pathogenesis, manifestations, diagnosis, and autopsy contribution to addressing these CDH.
The case involves a 4-month-old female infant, with no pathological symptoms since birth nor perinatal findings, who presented sudden respiratory difficulties after breastfeeding. The infant reportedly died during transport to pediatric emergencies; thus, no resuscitation maneuvers could be performed at the emergencies arrival. As a result of the unclear cause of death, a medicolegal autopsy was ordered by the prosecutor, and the body was thus transferred for autopsy. A polymerase chain reaction (PCR) test for Covid-19 has been performed (postmortem), which was negative.
External examination found marked cyanosis with no evidence of trauma. The body measurements were as follows: bodyweight 7000 g, body length 64 cm, and head circumference 41 cm. Upon opening the chest cavity, the stomach, markedly distended, was occupying much of the left pleural cavity (Fig. 1). The left lung was compressed and displaced superiorly, and the heart was also compressed and deviated to the right. This mediastinal deviation was due to an ascension of the stomach into the chest cavity through a 2 × 1.5 cm defect in the posterior left hemidiaphragm (Fig. 2a). A white creamy material was found (150 mL) within the stomach, supporting the history of breastfeeding when the episode occurred. The right hemidiaphragm was intact with no evidence of laceration or hemorrhage of the diaphragm, and no pleural or pericardial effusions were present. Further examination remarked an ecchymotic appearance of the stomach portion entrapped in the hernia defect (Fig. 2b) suggesting recent strangulation of the stomach. The left lung weighed 30 g, and the right lung weighed 50 g. No heart (weighing 35 g) defect was found at dissection nor any other defect on the remaining autopsy findings.
The histology study showed alveolar collapse with the presence of a polymorphic inflammatory infiltrate of the left lung (Fig. 3a) consistent with atelectasis associated with signs of pulmonary infection. The diaphragm histology study (Fig. 3b) showed normal muscle cells component, while chronic inflammatory changes of the gastric mucosa with vascular congestion were found (Fig. 3c). No toxic substances were detected in the toxicology study, ruling out the possibility of poisoning which could explain the death.
The cause of death was concluded as a consequence of acute respiratory failure related to a diaphragmatic hernia with severe mediastinal deviation.
The reported case describes the death of an infant due to late-presenting CDH which was incidentally discovered during the autopsy. Delayed presentation in late childhood or adolescence represents a dilemma in diagnosis, as 16% of infants with late-presenting CDH are reported to have previously normal chest radiography, and initial radiographic findings are misinterpreted in 25 to 62% of cases (Kadian et al. 2009; Kumbhar et al. 2019). As such, it may be an overlooked cause of mortality. This was not our case, as the infant did not report any respiratory symptoms since birth according to her parents.
The pathogenesis of CDH is not yet fully understood (Klaassens et al. 2009; Kosiński and Wielgoś 2017); however, diaphragm defects are suspected to result from aberrations in the development of the pleuroperitoneal folds (PPF) and pericardial-peritoneal ducts, an anomaly in the proliferation of the mesenchymal components of the PPF, or impaired migration of somite-derived pre-muscular and nerve cells (Kosiński and Wielgoś 2017). The defect occurs very early in pregnancy (10–12 weeks of gestation), which corresponds to the time of the diaphragm development (Sefton et al. 2018) and is detected through a routine ultrasound at 22 to 28 weeks of gestation. The diaphragmatic structures do not extend toward each other or fuse during development, resulting in an incomplete diaphragm or a complete diaphragm with insufficiently muscled and therefore weak regions (Solomon and Hayes 2016). In our case and according to the histology study, the diaphragm has normally developed with normal muscular cells, except for the defect area which corresponded to an incomplete diaphragm structure.
The most common form of CDH is the Bochdalek hernia (85% of all types of CDH) (Tartar et al. 2018) as supported by the literature review (Table 1). This anomaly accounts for 8% of all major congenital anomalies, with an incidence of 1 in 2000 to 4000 births (Centers for Disease Control and Prevention 2016), the majority being approximately 3 cm in diameter (Lally et al. 2007; Tartar et al. 2018). They occur posteriorly and are due to a defect in the posterior attachment of the diaphragm when there is a failure of pleuroperitoneal membrane closure in utero. They are frequently left sided (Tartar et al. 2018), owing to a later diaphragm closure in fetal life than the right side, which may also explain the asymmetric occurrence. Other types of CDH include the Morgagni hernia (~27%) and central hernia (~2–3%) (Mehollin-Ray 2020) (Table 1). Morgagni hernias refer to the herniation through the foramen of Morgagni (i.e., small defects in the posterior aspect of the anterior thoracic wall between the sternal and costal attachments of the diaphragm). When compared to Bochdalek hernias, Morgagni hernias tend to be anterior, more often right sided (~90%), and at low risk of prolapse (Mohamed et al. 2020). In our case, the defect corresponded to a Bochdalek hernia, and a missing hernia sack reported at autopsy suggested a congenital defect. Usually, large Bochdalek’s hernias are associated with pulmonary hypoplasia resulting in respiratory distress, while small Bochdalek’s hernias may allow normal lung development and thus remain asymptomatic until the occurrence of a triggering event (De et al. 2013). In this case, it is presumed that the hernia was initially small at birth, causing few or no symptoms. The precipitating event that ultimately led to acute respiratory decompensation was an airway infection in the poorly ventilated atelectatic areas of the collapsed lung. When the stomach reached its full capacity (after feeding), it exerted a mechanical compression on the ipsilateral lung causing severe mediastinal deviation and compression of the heart and upper respiratory tracts. The important volume of the herniated abdominal content caused an obstructive shock and asphyxia, consistent with the marked cyanosis found at the body examination.
From a forensic point of view, herniation of abdominal contents into the pleural cavity may be a postmortem artifact caused by pressure buildup in the abdominal cavity due to putrefaction (with a compromise of the structural integrity of the diaphragm), by cardiorespiratory resuscitation maneuvers before death, by direct penetrating injury (gunshot/stab injuries), or less commonly, secondary to blunt abdominal trauma (motor vehicle accidents, falls, crush injuries) (James et al. 1999; Thompson et al. 2016; Elibol et al. 2022). Forensics should hence be aware that some hernias are acquired, and any traumatic origin must first be eliminated before considering the hypothesis of a congenital hernia. Ultimately, a herniation may be unrelated to death. In our case, there was no traumatic context nor any performed resuscitation maneuvers reported before death. There were also no abdominal nor thoracic organ injuries at autopsy findings suggesting blunt trauma. CDH was retained as the cause of death due to lung compression with respiratory failure and/or mediastinal shift after postmortem investigations.
The autopsy here was crucial for elucidating the cause of death. As such, the autopsy is a means of providing an accurate understanding of the cause of death to minimize outcome bias. It provides families and medical caregivers with objective explanations for some respiratory distress etiologies that might be considered uncommon and not always mentioned in the main clinical guidelines (Chau et al. 2013). As late-presenting diaphragmatic hernia is associated with a wide range of clinical symptoms (Table 1), some manifestations such as difficulty breathing, cyanosis (blue color of the skin), abnormal chest development (with one side being larger than the other), or abdomen that appears caved in should make clinicians suspect this anomaly. This is all the more pertinent before developmental delays such as delays in the ability to roll over, sit, crawl, stand, or walk.
In conclusion, the presented case corresponds to a late-presenting CDH incidentally discovered during a sudden death autopsy. Symptoms revealing this defect were respiratory distress caused by the herniation of all the stomach into the chest cavity. Forensic pathologists should know of this malformation in order to apply the best autopsy techniques and thus allow positive feedback to pediatricians considering the possible legal implications. CDH will be retained as the cause of death only after eliminating all other etiologies of acquired herniation of the abdominal organ into the chest cavity.
Availability of data and materials
Congenital diaphragmatic hernia
Coronavirus disease 2019
Polymerase chain reaction
Bagłaj M, Dorobisz U (2005) Late-presenting congenital diaphragmatic hernia in children: a literature review. Pediatr Radiol 35:478–488. https://doi.org/10.1007/s00247-004-1389-z
Blibech S, Kasdallah N, Ben Salem H et al (2014) Hernie diaphragmatique congénitale droite suite à un pyopneumothorax neonatal à Streptocoque B [Right congenital diaphragmatic hernia following neonatal Streptococcus B] pyopneumothorax. Tunis Med 92:232–233
Bolino G, Gitto L, Serinelli S, Maiese A (2015) Autopsy features in a newborn baby affected by a central congenital diaphragmatic hernia. Med Leg J 83:51–53. https://doi.org/10.1177/0025817214554871
Borys D, Taxy JB (2004) Congenital diaphragmatic hernia and chromosomal anomalies: autopsy study. Pediatr Dev Pathol 7:35–38. https://doi.org/10.1007/s10024-003-2133-7
Centers for Disease Control and Prevention (2016) Data & statistics on birth defects. Division of birth defects and developmental disabilities, Atlanta https://www.cdc.gov/ncbddd/birthdefects/data.html. Accessed 26 Nov 2021
Chau D, Srour H, Rolf C et al (2013) Death by late-presenting Bochdalek hernia in infant soon after congenital cardiac repair. World J Pediatr Congenit Hear Surg 4:213–216. https://doi.org/10.1177/2150135112472348
Chhanabhai M, Avis S, Hutton C (1995) Congenital diaphragmatic hernia. A case of sudden unexpected death in childhood. Am J Forensic Med Pathol 16:27–29
Clugston RD, Greer JJ (2007) Diaphragm development and congenital diaphragmatic hernia. Semin Pediatr Surg 16:94–100. https://doi.org/10.1053/j.sempedsurg.2007.01.004
De A, Stein JE, Thompson M, Perez I (2013) Persistent pneumonia in an infant keeping an open mind. Ann Am Thorac Soc 10:514–517. https://doi.org/10.1513/AnnalsATS.201305-131CR
Doyle NM, Lally KP (2004) The CDH study group and advances in the clinical care of the patient with congenital diaphragmatic hernia. Semin Perinatol 28:174–184. https://doi.org/10.1053/j.semperi.2004.03.009
Elibol P, Özon A, Demir G et al (2022) Ileus and late-onset traumatic diaphragmatic hernia presenting with vomiting and dyspnea: a case report. Turkish J Pediatr Emerg Intensive Care Med 9:51–54. https://doi.org/10.4274/cayd.galenos.2021.07742
Ghabisha S, Ahmed F, Al-wageeh S et al (2021) Delayed presentation of congenital diaphragmatic hernia : a case report. Pan African Med J 40:2–7. https://doi.org/10.11604/pamj.2021.40.242.32113
Greer JJ (2013) Current concepts on the pathogenesis and etiology of congenital diaphragmatic hernia. Respir Physiol Neurobiol 189:232–240. https://doi.org/10.1016/j.resp.2013.04.015
Hmadouch SA, Barkat A (2020) Congenital diaphragmatic hernia: a pathology not always easy to diagnose. Pan Afr Med J 36:353. https://doi.org/10.11604/pamj.2020.36.353.13525
James R, Gilbert J, Byard R (1999) Posttraumatic diaphragmatic hernia and death -etiologic factor or putrefactive artifact. Am J Forensic Med Pathol 20:66–69. https://doi.org/10.1097/00000433-199903000-00016
Kadian Y, Rattan K, Verma M, Kajal P (2009) Congenital diaphragmatic hernia: misdiagnosis in adolescence. J Indian Assoc Pediatr Surg 14:31–33. https://doi.org/10.4103/0971-9261.44775
Kalvandi G, Shahramian I, Bazi A et al (2018) A case report and literature review of the late presenting congenital diaphragmatic hernia. Ann Pediatr Surg 14:187–189. https://doi.org/10.1097/01.XPS.0000535046.46728.c6
Karamanoukian HL, Glick PL (2003) Congenital diaphragmatic hernia. Ann Thorac Surg 75:1059–1060. https://doi.org/10.1016/s0003-4975(02)04684-2
Keijzer R, Puri P (2010) Congenital diaphragmatic hernia. Semin Pediatr Surg 19:180–185. https://doi.org/10.1053/j.sempedsurg.2010.03.001
Kesavan A, Thuruthiyath N, Balakrishnan I (2017) Diaphragmatic hernia-rare case scenarios. Arch Paediatr Dev Pathol 1:1012
Klaassens M, de Klein A, Tibboel D (2009) The etiology of congenital diaphragmatic hernia: Still largely unknown? Eur J Med Genet 52:281–286. https://doi.org/10.1016/j.ejmg.2009.05.005
Kosiński P, Wielgoś M (2017) Congenital diaphragmatic hernia: pathogenesis, prenatal diagnosis and management - literature review. Ginekol Pol 88:24–30. https://doi.org/10.5603/GP.a2017.0005
Kotis A, Tsikouris P, Guindaglia L (2009, 2009) Congenital diaphragmatic hernia. BMJ Case Reportsse Rep:bcr2007051391. https://doi.org/10.1136/bcr.2007.051391
Kumbhar S, Siddiqui S, Thakrar P (2019) Avoiding misdiagnosis in postnatal presentation of congenital diaphragmatic hernia: a report of two cases and review of radiologic features. Radiol Case Rep 14:1288–1292. https://doi.org/10.1016/j.radcr.2019.07.016
Lally KP, Lally PA, Lasky RE et al (2007) Defect size determines survival in infants with congenital diaphragmatic hernia. Pediatrics 120:e651–e657. https://doi.org/10.1542/peds.2006-3040
Lava JR, Hettwer GA, Reginatto CJ et al (2012) Congenital diaphragmatic Bochdaleck hernia: case report. Int Arch Med 5:2–5. https://doi.org/10.1186/1755-7682-5-30
Lemos SPP, Lemos PVRB, Coelho NALR et al (2015) Congenital diaphragmatic hernia with delayed diagnosis: report of two cases. Case Reports Clin Med 04:114–118. https://doi.org/10.4236/crcm.2015.43025
Loukas M, El-Sedfy A, Shane Tubbs R et al (2008) Vincent Alexander Bochdalek (1801-1883). World J Surg 32:2324–2326. https://doi.org/10.1007/s00268-008-9686-6
Mehollin-Ray AR (2020) Congenital diaphragmatic hernia. Pediatr Radiol 50:1855–1871. https://doi.org/10.1016/s0003-4975(02)04684-2
Mobilia F, Andreola S, Gentile G et al (2013) Lethal bochdalek hernia in a three-year-old: pathological findings and medicolegal investigation in accusation of malpractice. Med Sci Law 53:51–54. https://doi.org/10.1258/msl.2012.012023
Mohamed M, Al-Hillan A, Shah J et al (2020) Symptomatic congenital Morgagni hernia presenting as a chest pain: a case report. J Med Case Rep 14:1–5. https://doi.org/10.1186/s13256-019-2336-9
Muien MZA, Jeyaprahasam K, Krisnan T et al (2021) Rare late-presentation congenital diaphragmatic hernia mimicking a tension pneumothorax. Radiol Case Rep 16:2542–2545. https://doi.org/10.1016/j.radcr.2021.06.024
Salaçin S, Alper B, Çekin N, Gülmen MK (1994) Bochdalek hernia in adulthood: a review and an autopsy case report. J. Forensic Sci. 39:13692J
Sefton EM, Gallardo M, Kardon G (2018) Developmental origin and morphogenesis of the diaphragm, an essential mammalian muscle. Dev Biol 440:64–73. https://doi.org/10.1016/j.ydbio.2018.04.010
Solomon N, Hayes J (2016) A sudden infant death due to congenital diaphragmatic hernia. Acad Forensic Pathol 6:720–730. https://doi.org/10.23907/2016.068
Tartar T, Saraç M, Bakal Ü, Kazez A (2018) Bochdalek hernias in children with late presentation. Turk Pediatr Ars 53:245–249. https://doi.org/10.5152/TurkPediatriArs.2018.0039
Thompson M, Wills S, Byard RW (2016) Forensic features of lethal late-presenting diaphragmatic hernias. J Forensic Sci 61:1261–1265. https://doi.org/10.1111/1556-4029.13142
Uinarni H, Nike F, Budianto IR et al (2020) Newborn female with congenital diaphragmatic hernia (Bochdalek hernia): a case report. Int J Pharm Res 12:2138–2143. https://doi.org/10.31838/ijpr/2020.12.03.306
Woodbury JM, Bojanić K, Grizelj R et al (2019) Incidence of congenital diaphragmatic hernia in Olmsted County, Minnesota: a population-based study. J Matern Fetal Neonatal Med 32:742–748. https://doi.org/10.1080/14767058.2017.1390739
Xia B, Hong C, Tang J et al (2017) Congenital diaphragmatic hernia in association with congenital short esophagus. Med (United States) 96:2–4. https://doi.org/10.1097/MD.0000000000008996
We thank the Department of Pathological Anatomy and Cytology for their expertise.
No financial support has been received for this manuscript.
Competing of interests
The authors declare that they have no competing interests.
Ethics approval and consent to participate
Consent for publication
An oral consent was taken from the deceased’s descendant after informing him of the purpose of the case report. No private details of no scientific relevance were mentioned within the case report; thus, we did not need to take written consent.
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Rights and permissions
Open Access This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article's Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article's Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creativecommons.org/licenses/by/4.0/.
About this article
Cite this article
Ben Abderrahim, S., Jedidi, M., Ben Daly, A. et al. Death by late presenting of diaphragmatic hernia in an infant: case report and review of the literature. Egypt J Forensic Sci 12, 39 (2022). https://doi.org/10.1186/s41935-022-00299-x
- Congenital diaphragmatic hernia
- Case report
- Sudden death
