Unexpected death in a newborn due to a congenital partial pericardial defect: a case report

Abstract

Background

Pericardial defects are rare anatomical variations that can present as an isolated variation or be associated with other conditions. They are usually asymptomatic and misdiagnosed conditions, and given their rarity, partial pericardial defects can have devastating outcomes. The sudden death of an apparently healthy newborn certainly raises concerns, and a medico-legal investigation is crucial in establishing the cause of death. This case report highlights the importance of awareness on the part of obstetric professionals of the lethal outcomes of pericardial partial congenital defects. This case also demonstrates the difficulty of establishing a correct diagnosis.

Case presentation

The autopsy of a 15-h-old neonate revealed a partial pericardial defect ending in a biventricular strangulation by the defective pericardium. Other findings, such as the patency of the arterial ductus, a subarachnoid hemorrhage, and aspiration of amniotic fluid, were also reported.

Conclusions

Although imaging techniques have evolved, fetal detection of cardiac abnormalities can be tricky, especially when occurring as an isolated variation.

Background

The pericardium is a serosal-fibrous double sac surrounding the heart, and its fibrous ligaments enable cardiac stability (Standring et al. 2015). Pericardial defects can be categorized into congenital and acquired. Congenital pericardial malformations are considered rare, with an incidence of < 1 in 10,000–14,000. These defects also present a 3:1 male predominance, and no family link has been reported (Pernot et al. 1972; Yamano et al. 2004; Shah and Kronzon 2015; Rehkämper et al. 2017; Abbas et al. 2005).

The pericardium has various protective and physiological functions. It shields the heart from potential infections from the lungs as well as from mechanical trauma (Cuccuini et al. 2013; Baue and Blakemore 1972). Due to its ligaments, the pericardium maintains the heart’s position inside the thorax, and its fibers prevent overdistensions of the heart. The pericardial fluid reduces the friction of the cardiac surface at the time of systole and diastole (Standring et al. 2015; Shah and Kronzon 2015; Baue and Blakemore 1972; Tubbs and Yacoub 1968).

This case report aims to describe a pericardium variation which led to the sudden death of an apparently healthy newborn. It also highlights the importance of a medico-legal investigation in establishing an unusual cause of death.

Case presentation

This case involves a healthy newborn who died unexpectedly 15 h after delivery. The maternal-fetal medical history specified no pregnancy complications; however, the records report a difficult prolonged labor with a normal vaginal delivery. Although the delivery was difficult, the neonate did not require any intervention or resuscitation maneuvers in the delivery room and was released to the joint accommodation with the parents.

After 5 h, the neonate becomes hypoactive, with reduced reflexes, presenting apnea and a bulging of the fontanelle. Cardiopulmonary resuscitation maneuvers were given as well as orotracheal intubation to little avail. The neonate was pronounced dead 15 h after birth.

The brain and the heart-lungs block underwent histopathological analysis (see Fig. 1a–c). The results of the post-mortem examination revealed acute hypoxic encephalitis, possibly the result of neonatal brain trauma. Based on the nature of the death, the forensic pathological analysis was carried out revealing a subarachnoid hemorrhage extended to the neural tissue with cerebral intra-parenchymatous hemorrhage as well as the pulmonary aspiration of amniotic fluid. The cardiovascular findings were a patent arterial duct, and the most unsettling finding was a congenital partial pericardial defect leading to a biventricular constriction, confirmed by a histopathological study that showed the partial pericardial defect engendering a biventricular impingement. The histopathological examination also showed a discrete lymphocytic infiltration in the constricted area of the myocardium. Conversely, there was no indication of fibrosis or tissue necrosis. Concerning the coronary vessels, they were preserved, showing no signs of fibrosis or stenosis (see Fig. 1d). The neonate died of unmanageable congestive heart failure 15 h after birth.

Fig. 1
figure 1

ac The heart-lung block. a, b The transversal strangulation of the partial pericardial defect, anterior (a) and posterior (b) views. In detail (c), the patent ductus arteriosus and in the histopathology of the strangulation site (d)

Discussion

Congenital pericardial defects can be classified according to the location and whether the absence of the pericardium is complete or partial (Tubbs and Yacoub 1968; Faridah and Julsrud 2002; Centola et al. 2009; Southworth and Stevenson 1938). The most frequent defect is the left side absence of the pericardium while right side defects and complete agenesis are quite rare (Abbas et al. 2005; Southworth and Stevenson 1938). Partial defects are rarer but of clinical importance as they can cause myocardial strangulation and death; however, they are usually asymptomatic or paucisymptomatic (Rehkämper et al. 2017; Centola et al. 2009; Sergio et al. 2019).

The pericardium has a mesodermal embryologic origin which starts around the fourth week of development (Faridah and Julsrud 2002). A common cardinal vein divides into the ventral, originating the pneumopericardium, and the dorsal membranes, where the pleuroperitoneal membrane arises by the fifth week (Moore et al. 2018; Kim et al. 2007). These membranes merge with the medial wall of the pleuroperitoneal canal, then the pleural and pericardial cavities become disconnected. Pericardial defects result as a consequence of the failure of pleuropericardial membranes to fuse entirely or as a failure in its formation (Moore et al. 2018; Kim et al. 2007) as well as the premature atrophy of the left common cardinal vein (Brulotte et al. 2007). These defects are usually left-sided, allowing communication between the pericardial and pleural cavities. More rarely, there can be herniation of the left atrium through the pleural cavity (Moore et al. 2018).

Because most cases are asymptomatic, diagnosis tends to be accidental resulting from imaging studies or surgeries searching for other pathologies or during autopsy procedures, which probably means that its real prevalence is underestimated (Khayata et al. 2020; Parmar et al. 2017; Van Son et al. 1993). Furthermore, most partial congenital aplasia is non-diagnosed and joins the statistics of undefined causes of death. Diagnostics for suspected pericardium defects have evolved with the development of high-definition image studies and protocols designed to identify such embryological anomalies (Faridah and Julsrud 2002; Khayata et al. 2020; Parmar et al. 2017).

Compression and strangulation of adjacent structures including the heart and its parts can happen in partial defects, as in this case report, leading to ischemia, necrosis, and death (Baue and Blakemore 1972; Tubbs and Yacoub 1968; Khayata et al. 2020). The absence of the inferior pericardium is rare in adults (Abbas et al. 2005), maybe due to its incompatibility with life, and can be associated with diaphragmatic defects and herniation of abdominal organs into the pericardial sac (Abbas et al. 2005; Centola et al. 2009).

Congenital pericardial defects are usually found as an isolated variation although they can be associated with other cardiac malformations. Thirty percent of patients have cardiac associated defects, such as a bicuspid aortic valve, persistent ductus arteriosus, an atrial septal defect, or tetralogy of Fallot. It can also be a feature of Cantrell’s pentalogy, which is classically composed of defects in the diaphragmatic pericardium, anterior diaphragmatic hernia, supraumbilical abdominal wall defects, agenesis of the lower sternum, and intracardiac malformation; however, it can present partially with different combinations of these conditions. These malformations can also be associated with genetic syndromes, for example, VACTERL syndrome which leads to several anatomical malformations, among them pericardial defects (Rehkämper et al. 2017; Khayata et al. 2020; Parmar et al. 2017).

There are few articles and case reports showing this condition in newborns, which hinders a clear understanding of the epidemiology of this condition. However, pericardium defects are usually associated with other developmental anomalies which can support early diagnosis as well as prevent devasting outcomes. Prenatal perception of an irregular murmur may be the trigger for initiating further investigations by the obstetrician. Although fetal cardiac ultrasound is good for the detection of complex heart diseases that also involve the pericardium, when isolated, its sensitivity is reduced. Fetal sonography is the most common approach to heart conditions in neonates, but although cardiac defects are the most common congenital defects, the sonographic diagnosis of these conditions is not easy, especially when not associated with other features. The addition of other dimensions (e.g., three- and four-dimensional ultrasounds) can also be helpful in the early detection of pericardium abnormalities (Centola et al. 2009; Sohaey and Zwiebel 1996).

Generally, treatment is not required for congenital pericardium defects; however, prophylactic repair in partial defects is required when herniation occurs or is a threat, and in symptomatic patients needing surgical pericardiectomy, pericardioplasty, primary closure, or others, but for these, diagnosis has to be made before it is too late (Shah and Kronzon 2015; Khayata et al. 2020).

Conclusions

Although imaging techniques have evolved, fetal detection of cardiac abnormalities can be tricky, especially when occurring as an isolated variation.
